System And Components
278-5672 WIRING GP-ELECTRONIC CONTROLAN ATTACHMENT
Group No: 278-5672
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 1315526 | 2 FASTENER GP-WIRING HARNESS | 1 | |
| 2785639 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 5 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 2 | |
| 2642354 | 7 HARNESS AS-CONTROL | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 5P6001 | TUBE-HEAT SHRINK (4.75-MM DIA)(0.2-M) | ||
| 6I4348 | BOOT (40-PIN) | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8T8736 | RECEPTACLE-CONNECTOR (9-PIN) | 1 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(20-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(20-CM) | ||
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(20-CM) | ||
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 2 | |
| 1342540 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1532707 | CABLE-ELECTRICAL (2-CONDUCTOR, 18-GA)(162-CM) | ||
| 1607689 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 2370336 | COVER (CONNECTOR)(ENDBELL) | 1 | |
| 4B5324 | 8 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 4P8134 | 9 CLIP (LADDER) | 1 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9S8752 | 11 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6258 | 12 SCREW-MACHINE (6-32X0.5-IN) | 4 |
