System And Components
350-7151 WIRING GP-ELECTRONIC CONTROLAN ATTACHMENT
Group No: 350-7151
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 27 | |
| 2061345 | 2 STRAP-CABLE | 1 | |
| 2249222 | 3 BRACKET | 1 | |
| 2379960 | 4 CLIP (LADDER) | 2 | |
| 2899520 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2905664 | 6 STRAP-CABLE | 1 | |
| 3169351 | 7 MOUNTING-CABLE TIE | 3 | |
| 3264514 | 8 TIE-CABLE | 1 | |
| 3479417 | 9 BRACKET | 1 | |
| 3603501 | 10 HARNESS AS-ENGINE | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 3603502 | HARNESS AS-ENGINE | 1 | |
| 3S2093 | STRAP-CABLE | 2 | |
| 6K0806 | STRAP-CABLE | 1 | |
| 8T8737 | PLUG-SEAL | 56 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(55-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 178 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 178 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552256 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 6 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2305008 | PLUG AS-CONNECTOR (4-PIN) | 2 | |
| 2647031 | SEAL-CONNECTOR | 1 | |
| 2305010 | PLUG AS-CONNECTOR (6-PIN) | 2 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2388247 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2645732 | PLUG AS-CONNECTOR (120-PIN) | 1 | |
| 2887324 | SEAL-CONNECTOR | 1 | |
| 2743783 | CAP-SEAL | 2 | |
| 2818801 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2818804 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2818811 | PLUG AS-CONNECTOR (6-PIN) | 2 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2895150 | SLEEVE (282-CM) | ||
| 2895151 | SLEEVE (111-CM) | ||
| 3601328 | RECEPTACLE AS-CONNECTOR (6-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 6 | |
| 2305011 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 10 | |
| 0S0509 | 12 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 1 | |
| 0S1617 | 14 BOLT (5/16-18X0.75-IN) | 1 | |
| 1005725 | 15 STUD (3/8-16X1.25-IN) | 1 | |
| 1325789 | 16 CLIP (LADDER) | 5 | |
| 1A5822 | 17 BOLT (1/2-13X2.75-IN) | 1 | |
| 2771873 | 18 CLIP (LADDER) | 2 | |
| 2H3755 | 19 BOLT (5/16-18X0.43-IN) | 1 | |
| 3523968 | 20 CLIP (LADDER) | 3 | |
| 3523970 | 21 CLIP (LADDER) | 1 | |
| 4P7429 | 22 CLIP (LADDER) | 1 | |
| 4P7581 | 23 CLIP (LADDER) | 4 | |
| 4P8134 | 24 CLIP (LADDER) | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 21 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5S0003 | 27 NUT (5/16-18-THD) | 2 | |
| 6V5215 | 28 BOLT (M8X1.25X16-MM) | 1 | |
| 7X0579 | 29 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 8R3652 | 30 SPACER (13.86X21.34X37-MM THK) | 1 | |
| 9M1974 | 31 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9S8752 | 32 NUT-FULL (3/8-16-THD) | 3 |
