361-9395 INSTRUMENT GPType 2

Group No: 361-9395

Part Number	Part Name	Qty
2V7087	1 LENS-AMBER	1
2V7088	2 LENS-RED	1
3E0156	3 SWITCH GP-START	1
6V8362	SCREW-MACHINE (8-32X0.31-IN)	1
7T6799	NUT-MOUNTING (1-32-THD)	1
9B7233	LOCKWASHER	1
5P8500	4 KEY	1
1003245	5 LAMP (24-VOLT)	2
8C6354	6 CAP-RECEPTACLE (ET CONNECTOR)	1
1560518	7 SOCKET AS	2
6V8367	LOCKWASHER	1
6V8382	NUT-HEX (11/16-27-THD)	1
1673593	8 STRAP	1
1893158	9 SUPPRESSOR-ARC	1
2418368	10 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)	1
3012980	11 SWITCH AS-TOGGLE (ROTOR TURNING)(IDLE, HIGH, LOW)	1
1028803	KIT-RECEPTACLE (3-PIN)	1
3E3390	PIN-CONNECTOR (16-GA TO 18-GA)	3
6T3631	NUT-HEX (15/32-32-THD)	1
6T3632	LOCKWASHER	1
3619400	12 HARNESS AS-PANEL	1
3715910	13 FILM-INSTRUMENT	1
5441541	14 HARNESS AS-WIRING	1
5456553	15 CONVERTER	1
0965962	16 WASHER-HARD (3.4X7X0.8-MM THK)	4
3619728	17 PLATE	1
3660246	18 PLATE-NUT	1
3C6969	19 NUT (M3X0.5-THD)	4
5360459	20 INDICATOR (COOLANT TEMPERATURE)	1
5360460	21 INDICATOR (OIL PRESSURE)	1
5360462	22 INDICATOR AS (FUEL PRESSURE)	1
5360465	23 INDICATOR (VOLTMETER)	1
5360466	24 INDICATOR (TACHOMETER)	1
5441544	25 BOX AS-INSTRUMENT	1
6V9632	NUT-WELD (M6X1-THD)	6
9X2032	NUT-WELD (M4X0.7-THD)	2
6T3643	26 CIRCUIT BREAKER AS (15-AMPERE)(30-VOLT)	2
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
6T3645	27 CIRCUIT BREAKER GP (60-AMPERE)(30-VOLT)	1
6V9671	28 SCREW-MACHINE (M3X0.5X12-MM)	4
6V9672	29 SCREW-MACHINE (M4X0.7X16-MM)	4
8C9660	30 WASHER (4.6X7.9X0.8-MM THK)	2
8T0337	31 SCREW-MACHINE (M4X0.7X12-MM)	2
8T4138	32 BOLT (M6X1X20-MM)	2
9X2044	33 SCREW-TRUSS HEAD (M6X1X16-MM)	4
9X8256	34 WASHER (6.6X12X2-MM THK)	2
9X8486	35 SCREW-MACHINE (8-32X0.75-IN)	6
