System And Components
434-2730 LINES GP-AIRS/N F2Z1-UP
Group No: 434-2730 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2566453 | 1 SENSOR-TEMPERATURE (2-PIN)(AIR INLET) | 1 | |
| 2566454 | 2 SENSOR-TEMPERATURE (2-PIN)(CHARGE AIR) | 1 | |
| 3203063 | 3 SENSOR GP-PRESSURE (ATMOSPHERIC AIR) | 1 | |
| 3922532 | 4 HOSE | 1 | |
| 3922591 | 5 HOSE-AIR | 1 | |
| 3922592 | 6 TUBE AS-AIR | 1 | |
| 3922595 | 7 HOSE-AIR INLET | 1 | |
| 3922599 | 8 HOSE | 1 | |
| 3922601 | 9 ELBOW AS | 1 | |
| 4445017 | 10 BRACKET AS | 1 | |
| 4579522 | 11 HOSE-AIR INLET | 1 | |
| 1257131 | 12 CLIP | 1 | |
| 1440367 | 13 CLAMP-HOSE | 2 | |
| 2287100 | 14 SEAL-O-RING | 1 | |
| 2287103 | 15 SEAL-O-RING | 1 | |
| 2385080 | 16 SEAL-O-RING | 1 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4984 | 19 CLAMP-HOSE | 1 | |
| 8T4985 | 20 CLAMP-HOSE | 1 | |
| 8T4987 | 21 CLAMP-HOSE | 1 | |
| 8T6703 | 22 CLAMP-HOSE | 1 | |
| 9X2201 | 23 CLAMP-HOSE | 2 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 1 |
