System And Components
493-9450 CLUTCH GP-POWER TAKE-OFFS/N KWJ1-UP
Group No: 493-9450
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5B2410 | 1 HOSE AS | 1 | |
| 1L6931 | 2 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 4B7270 | 4 CONE-BEARING | 2 | |
| 6B3223 | 5 CUP-BEARING | 2 | |
| 6L5151 | 6 KEY-WOODRUFF | 2 | |
| 8B7121 | 7 FITTING-HYDRAULIC | 2 | |
| 1083560 | 8 PLATE-WARNING (POWER TAKE-OFF) | 1 | |
| 1083561 | 9 PLATE-INSTRUCTION (POWER TAKE-OFF) | 1 | |
| 2760744 | 10 CAP-PLUG | 2 | |
| 4900188 | 11 LINK | 8 | |
| 4903992 | 12 SLEEVE | 1 | |
| 4904088 | 13 LOCK | 1 | |
| 4904090 | 14 RING | 1 | |
| 4905401 | 15 PLATE-CENTER | 1 | |
| 4905402 | 16 LEVER-CLUTCH | 4 | |
| 4905442 | 17 PLATE | 2 | |
| 4908001 | 18 WASHER-SPRING | 8 | |
| 4908035 | 19 RETAINER-BEARING | 1 | |
| 4920192 | 20 PLATE AS | 1 | |
| 4906496 | SPRING-PIN | 1 | |
| 4920193 | PIN | 1 | |
| 4920217 | 21 COLLAR AS-SLEEVE | 1 | |
| 0L1648 | BOLT (3/8-24X2.5-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4920219 | 22 YOKE AS | 1 | |
| 3B4506 | LOCKWASHER | 2 | |
| 1653929 | BOLT (3/8-16X1.5-IN) | 2 | |
| 4920221 | 23 LEVER AS-HAND | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 4920223 | 24 SHAFT-CLUTCH | 1 | |
| 4920224 | 25 SHAFT-CLUTCH | 1 | |
| 4939451 | 26 NUT | 1 | |
| 4939452 | 27 LOCK | 1 | |
| 4939453 | 28 RING-DRIVE | 1 | |
| 4939454 | 29 PLATE | 1 | |
| 4939455 | 30 CARRIER-BEARING | 1 | |
| 4939456 | 31 HOUSING-CLUTCH | 1 | |
| 4939457 | 32 KEY-WOODRUFF | 1 | |
| 4939458 | 33 HUB | 1 | |
| 5055753 | 34 CAP-GREASE | 4 | |
| 0S1614 | 35 BOLT (1/4-20X0.5-IN) | 2 | |
| 0S1617 | 36 BOLT (5/16-18X0.75-IN) | 1 | |
| 1A1460 | 37 BOLT (1/2-13X2-IN) | 6 | |
| 1H3338 | 38 LOCKWASHER | 2 | |
| 3B4508 | 39 LOCKWASHER | 6 | |
| 3B4627 | 40 PIN-COTTER | 4 | |
| 3B5301 | 41 PIN-COTTER | 8 | |
| 3F9556 | 42 LOCKWASHER | 1 | |
| 6F0253 | 43 LOCKWASHER | 1 | |
| 6L3967 | 44 PIN | 8 | |
| 6L3972 | 45 PIN | 4 | |
| 9S1354 | 46 NUT (5/8-18-THD) | 1 |
