System And Components
349-5143 LINES GP-TURBOCHARGER -WASTEGATES/N KWJ1-UP
Group No: 349-5143
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2901993 | 1 STRAP-CABLE | 3 | |
| 3177012 | 2 CLAMP-BAND | 2 | |
| 3368692 | 3 HOSE AS | 1 | |
| 3474867 | 4 PLATE AS | 1 | |
| 3649626 | 5 ELBOW AS | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 3649625 | ADAPTER-ELBOW | 1 | |
| 3649630 | 6 CONNECTOR AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3649629 | CONNECTOR | 1 | |
| 3649634 | 7 ELBOW AS | 1 | |
| 1716469 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3669288 | 8 TUBE AS-AIR | 1 | |
| 3669290 | 9 TUBE AS | 1 | |
| 3669293 | 10 TUBE AS | 1 | |
| 3669296 | 11 TUBE AS-AIR | 1 | |
| 1659755 | 12 STUD (M12X1.75X70-MM) | 3 | |
| 1A5350 | 13 CLIP | 1 | |
| 1V8230 | 14 SPACER (0.531X1X0.57-IN THK) | 2 | |
| 3422134 | 15 CLIP | 2 | |
| 3453350 | 16 CLIP | 2 | |
| 3H7654 | 17 WASHER-HARD (13.5X22.5X3-MM THK) | 1 | |
| 5P7970 | 18 NUT (M8X1.25-THD) | 2 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6H7062 | 20 SPACER (13.5X25X19-MM THK) | 1 | |
| 6V5839 | 21 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6317 | 22 BOLT (M10X1.5X20-MM) | 2 | |
| 6V8197 | 23 BOLT (M12X1.75X40-MM) | 1 | |
| 6V8836 | 24 BOLT (M6X1X14-MM) | 1 | |
| 6Y8114 | 25 SPACER (13.8X23.75X12.7-MM THK) | 1 | |
| 8K5440 | 26 CLIP | 1 | |
| 9M1974 | 27 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8267 | 28 WASHER (6.6X12X2-MM THK) | 1 | |
| 3374178 | 29 HOSE (12-CM) | ||
| 3304374 | 30 SLEEVE (22-CM) |
