System And Components
349-1267 LINES GP-FUELS/N KWJ1-UP
Group No: 349-1267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 4P7233 | 2 GROMMET | 2 | |
| 2873049 | 3 STUD (M10X1.5X50-MM) | 1 | |
| 3457589 | 4 HOSE AS | 1 | |
| 3474404 | 5 ADAPTER AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3474403 | ADAPTER-ELBOW | 1 | |
| 3491269 | 6 LINE AS-FUEL | 1 | |
| 3491270 | 7 LINE AS-FUEL | 1 | |
| 3501838 | 8 HOSE AS | 1 | |
| 3501839 | 9 HOSE AS | 1 | |
| 3528928 | 10 REGULATOR GP-FUEL PRESSURE | 1 | |
| 0307942 | 11 ELBOW | 1 | |
| 1448344 | 12 SPACER (11X19X20-MM THK) | 1 | |
| 2147568 | 13 SEAL-O-RING | 1 | |
| 2Y5829 | 14 NUT (M10X1.5-THD) | 1 | |
| 3256994 | 15 CLIP (SLOT) | 2 | |
| 3256995 | 16 CLIP (TAB) | 2 | |
| 3328555 | 17 ADAPTER AS | 1 | |
| 8M0506 | ADAPTER-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3491209 | 18 CLIP | 1 | |
| 3K1787 | 19 GROMMET | 2 | |
| 6V5839 | 20 WASHER (11X21X2.5-MM THK) | 5 | |
| 6V6317 | 21 BOLT (M10X1.5X20-MM) | 3 | |
| 8T0275 | 22 BOLT (M6X1X50-MM) | 2 | |
| 8T1887 | 23 CLIP (SLOT) | 2 | |
| 8T1888 | 24 CLIP (TAB) | 2 | |
| 9X8267 | 25 WASHER (6.6X12X2-MM THK) | 2 |
