System And Components
505-3249 HEATER GP-JACKET WATERS/N LNA1-UP
Group No: 505-3249
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3378774 | 1 ADAPTER AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 0694269 | ADAPTER | 1 | |
| 3844686 | 2 BRACKET | 1 | |
| 3845289 | 3 HEATER GP-JACKET WATER | 1 | |
| 5053255 | 4 THERMOSTAT AS | 1 | |
| 1757141 | 5 NUT-HEX FLANGE (M10X1.5-THD) | 1 | |
| 3383669 | 6 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 1 | |
| 3574580 | 7 ADAPTER AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3574579 | CONNECTOR | 1 | |
| 4D7388 | 8 CLIP | 1 | |
| 6V8801 | 9 NUT (3/8-16-THD) | 1 | |
| 7X7958 | 10 CLAMP-HOSE | 4 | |
| 8T4896 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 3844685 | 12 BRACKET | 1 | |
| 1757141 | 13 NUT-HEX FLANGE (M10X1.5-THD) | 2 | |
| 3383669 | 14 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 2 | |
| 3027411 | 15 HOSE (107-CM) | ||
| 3027411 | 15A HOSE (47-CM) | ||
| 5743368 | 16 BRACKET | 1 |
