System And Components
435-1847 PANEL GP-ELECTRONICS/N LNA1-UP
Group No: 435-1847
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1694481 | 1 HINGE AS | 2 | |
| 5P5637 | 2 SEAL (0.1-M) | ||
| 9X8124 | 3 SWITCH AS-MAGNETIC (24-VOLT)(RELAY) | 1 | |
| 1435084 | 4 BASE-LAMP | 2 | |
| 1435085 | 5 BLOCK-CONTACT | 2 | |
| 1435086 | 6 BLOCK-CONTACT | 1 | |
| 1694501 | 7 CLIP | 2 | |
| 2069512 | 8 CONTACT | 2 | |
| 2145791 | 9 SWITCH AS-ROTARY (REMOTE START) | 1 | |
| 2266446 | 10 SWITCH AS-PUSH BUTTON (STOP) | 1 | |
| 2615503 | COLLAR | 1 | |
| 2286935 | 11 BLOCK-CONTACT | 2 | |
| 2677280 | 12 GROMMET | 1 | |
| 3504303 | 13 GROMMET | 8 | |
| 3546426 | 14 MOUNTING GP-BOX | 1 | |
| 4227778 | 15 STRIP GP-TERMINAL | 1 | |
| 4227779 | 16 STRIP GP-TERMINAL | 1 | |
| 4227780 | 17 STRIP GP-TERMINAL | 1 | |
| 4394232 | 18 DOOR AS-CONTROL | 1 | |
| 4402036 | 19 SWITCH-OPERATOR (CONTROL) | 1 | |
| 4574964 | 20 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 39 | |
| 2035398 | INSERT-THREADED (M5X0.8-THD) | 2 | |
| 2518101 | INSERT-THREADED (M4X1-THD) | 9 | |
| 2356970 | 21 DUCT (380-MM) | ||
| 2356970 | 21A DUCT (425-MM) | ||
| 2356970 | 21B DUCT (730-MM EACH) | ||
| 0950742 | 22 SCREW-MACHINE (M6X1X16-MM) | 2 | |
| 1609633 | 23 SWITCH AS-PUSH BUTTON (OPERATOR) | 1 | |
| 2661570 | 24 LOCK | 1 | |
| 9X8256 | 25 WASHER (6.6X12X2-MM THK) | 2 | |
| 1003245 | 26 LAMP (24-VOLT) | 2 | |
| 5153506 | 27 GROMMET | 1 |
