435-1847 PANEL GP-ELECTRONICS/N LNA1-UP

Group No: 435-1847

Part Number	Part Name	Qty
1694481	1 HINGE AS	2
5P5637	2 SEAL (0.1-M)
9X8124	3 SWITCH AS-MAGNETIC (24-VOLT)(RELAY)	1
1435084	4 BASE-LAMP	2
1435085	5 BLOCK-CONTACT	2
1435086	6 BLOCK-CONTACT	1
1694501	7 CLIP	2
2069512	8 CONTACT	2
2145791	9 SWITCH AS-ROTARY (REMOTE START)	1
2266446	10 SWITCH AS-PUSH BUTTON (STOP)	1
2615503	COLLAR	1
2286935	11 BLOCK-CONTACT	2
2677280	12 GROMMET	1
3504303	13 GROMMET	8
3546426	14 MOUNTING GP-BOX	1
4227778	15 STRIP GP-TERMINAL	1
4227779	16 STRIP GP-TERMINAL	1
4227780	17 STRIP GP-TERMINAL	1
4394232	18 DOOR AS-CONTROL	1
4402036	19 SWITCH-OPERATOR (CONTROL)	1
4574964	20 PANEL AS	1
3E4304	INSERT-THREADED (M6X1-THD)	39
2035398	INSERT-THREADED (M5X0.8-THD)	6
2518101	INSERT-THREADED (M4X1-THD)	9
2356970	21 DUCT (730-MM EACH)
2356970	21A DUCT (560-MM)
2356970	21B DUCT (425-MM)
2356970	21C DUCT (380-MM)
8T0337	22 SCREW-MACHINE (M4X0.7X12-MM)	2
1609633	23 SWITCH AS-PUSH BUTTON (OPERATOR)	1
2661570	24 LOCK	1
9X8256	25 WASHER (6.6X12X2-MM THK)	2
1003245	26 LAMP (24-VOLT)	2
5153506	27 GROMMET	1
5C2890	28 NUT (M6X1-THD)	2
5W1405	29 WASHER (4.3X12X1-MM THK)	2
2354451	30 BOLT-FLANGE HEAD (M6X1X16-MM)	10
