System And Components
505-3387 PANEL GP-ELECTRONICS/N LNA1-UP
Group No: 505-3387
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1694481 | 1 HINGE AS | 2 | |
| 1274618 | 2 FUSE (25-AMPERE) | 1 | |
| 5P5637 | 3 SEAL (0.1-M) | ||
| 9X8124 | 4 SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 2069512 | 5 CONTACT | 2 | |
| 2145791 | 6 SWITCH AS-ROTARY (REMOTE START) | 1 | |
| 2266446 | 7 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 2615503 | COLLAR | 1 | |
| 2286935 | 8 BLOCK-CONTACT | 1 | |
| 2354451 | 9 BOLT-FLANGE HEAD (M6X1X16-MM) | 11 | |
| 2416070 | 10 GROMMET | 2 | |
| 2661570 | 11 LOCK | 1 | |
| 2677280 | 12 GROMMET | 1 | |
| 3504303 | 13 GROMMET | 7 | |
| 3546426 | 14 MOUNTING GP-BOX | 1 | |
| 3914275 | 15 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 4625400 | 16 DOOR AS | 1 | |
| 4651283 | 17 PANEL GP-ELECTRONIC | 1 | |
| 5053386 | 18 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 41 | |
| 2035398 | INSERT-THREADED (M5X0.8-THD) | 2 | |
| 2518101 | INSERT-THREADED (M4X1-THD) | 6 | |
| 0950742 | 19 SCREW-MACHINE (M6X1X16-MM) | 2 | |
| 1H4393 | 20 LOCKWASHER | 1 | |
| 8T0337 | 23 SCREW-MACHINE (M4X0.7X12-MM) | 1 | |
| 9X8256 | 24 WASHER (6.6X12X2-MM THK) | 4 | |
| 2177164 | 25 DUCT-WIRE (1150-MM) | ||
| 2177164 | 25A DUCT-WIRE (190-MM) | ||
| 2177164 | 25B DUCT-WIRE (873-MM) | ||
| 5153506 | 26 GROMMET | 1 | |
| 5C2890 | 27 NUT (M6X1-THD) | 2 |
