System And Components
366-0077 MUFFLER GPS/N LXJ1-UP
Group No: 366-0077
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7611 | 1 CAP AS-RAIN (EXHAUST) | 1 | |
| 2473393 | 2 CLAMP AS (V-BAND) | 2 | |
| 3368526 | 3 BELLOWS | 1 | |
| 3584175 | 4 TUBE AS | 1 | |
| 3584177 | 5 TUBE AS | 1 | |
| 3660079 | 6 MUFFLER AS | 1 | |
| 3841259 | 7 PLATE | 2 | |
| 3841260 | 8 PLATE | 1 | |
| 1757141 | 9 NUT-HEX FLANGE (M10X1.5-THD) | 12 | |
| 2892492 | 10 CLAMP-MUFFLER | 1 | |
| 3383669 | 11 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 12 | |
| 5H8331 | 12 GASKET | 1 | |
| 6V5686 | 13 BOLT (M16X2X50-MM) | 4 | |
| 8T1757 | 14 NUT (M16X2-THD) | 4 | |
| 9X8268 | 15 WASHER (17.5X30X3.5-MM THK) | 8 |
