Assembly
100%

526-9487 CIRCUIT BREAKER GPS/N LXJ1-UP

Group No: 526-9487
Part NumberPart NameQty
8L84131 STRAP-CABLE (WHITE)5
23494252 LINK (TERMINAL)2
23544513 BOLT-FLANGE HEAD (M6X1X16-MM)13
30183134 BLOCK-TERMINAL (4-TERMINAL)20
30183165 COVER-END2
34588356 BLOCK-TERMINAL2
34956417 PANEL AS-ENCLOSURE1
3E4304INSERT-THREADED (M6X1-THD)19
2048659RAIL (2-DM)
34956458 PANEL-CIRCUIT BREAKER1
34956679 PLATE-COVER1
349680810 MOUNT7
350430311 GROMMET2
356279912 KIT-MARKER1
374047313 BAR AS1
418322714 RELAY (24-VOLT)(CIRCUIT BREAKER)1
421443415 CONTACTOR1
470231217 HARNESS AS-PANEL1
1S9593STRAP-CABLE6
2L8081TERMINAL-RING (14-GA TO 16-GA, 1/2-IN SCREW)4
478446918 HARNESS AS-PANEL1
1S9593STRAP-CABLE3
526949919 CIRCUIT BREAKER GP (630-AMPERE)1
342991320 BOLT-FLANGE HEAD (M10X1.5X20-MM)4
4702311HARNESS AS-PANEL1
1S9593STRAP-CABLE15
3451120CONNECTOR AS2
