System And Components
379-0919 WIRING GP-PANELS/N LXJ1-UP
Group No: 379-0919
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 7X2621 | 2 BOLT (M10X1.5X12-MM) | 1 | |
| 2888608 | 3 FASTENER GP-WIRING HARNESS | 3 | |
| 3546510 | 4 BOX GP-CONNECTION | 1 | |
| 3978476 | 5 HARNESS AS-PANEL | 1 | |
| 3978477 | 6 HARNESS AS-PANEL | 1 | |
| 2089282 | 7 BOLT (M8X1.25X25-MM) | 1 | |
| 2939452 | 8 MOUNTING-CABLE TIE | 1 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 1 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 2 | |
| 1910348 | 13 GROMMET | 1 | |
| 2069512 | 14 CONTACT | 1 | |
| 2145791 | 15 SWITCH AS-ROTARY (REMOTE START) | 1 | |
| 2266446 | 16 SWITCH AS-PUSH BUTTON | 1 | |
| 2615503 | COLLAR | 1 | |
| 2284798 | 17 FILM-IDENTIFICATION (GROUND) | 1 | |
| 2286935 | 18 BLOCK-CONTACT | 1 | |
| 2391234 | 19 RESISTOR | 1 | |
| 2606682 | 20 RIVET | 12 | |
| 5C2890 | 21 NUT (M6X1-THD) | 2 | |
| 3504303 | 22 GROMMET | 8 | |
| 3562799 | 23 KIT-MARKER | 1 | |
| 3562800 | 24 KIT-MARKER | 1 | |
| 4206320 | 25 FILM-INFORMATION (PANEL IDENTIFICATIONS) | 1 | |
| 4215384 | 26 KIT-MARKER | 1 |
