System And Components
384-7456 LINES GP-FUELS/N LXE1-UP; ELM1-UP
Group No: 384-7456
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 1 | |
| 1083612 | 2 SPACER (11.13X19.05X53-MM THK) | 1 | |
| 1187809 | 3 PLATE | 1 | |
| 1375110 | 4 BRACKET | 1 | |
| 7W6158 | 5 HOSE AS | 1 | |
| 1665919 | 6 HOSE AS | 1 | |
| 3779611 | 7 CONNECTOR AS | 1 | |
| 0307937 | CONNECTOR-PORT | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1917805 | 8 ELBOW AS | 4 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 0307962 | 9 ELBOW | 1 | |
| 3537954 | 10 GROMMET | 4 | |
| 1653929 | 11 BOLT (3/8-16X1.5-IN) | 1 | |
| 0T0065 | 12 BOLT (3/8-16X3.5-IN) | 1 | |
| 1A2029 | 13 BOLT (3/8-16X1.125-IN) | 2 | |
| 2A2677 | 14 SPACER (10.7X17.14X19.05-MM THK) | 1 | |
| 1B7182 | 15 BOLT (5/16-18X1.25-IN) | 1 | |
| 4569487 | 16 VALVE AS-CHECK | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4569486 | VALVE-CHECK | 1 | |
| 3B1915 | 17 BOLT (3/8-16X1.375-IN) | 2 | |
| 3E4352 | 18 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5S0003 | 20 NUT (5/16-18-THD) | 2 | |
| 1645567 | 21 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 8T1889 | 23 CLIP (SLOT) | 4 | |
| 8T1890 | 24 CLIP (TAB) | 4 | |
| 3139614 | 25 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 8C5064 | 26 CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(31-CM) | ||
| 3S2093 | 27 STRAP-CABLE | 2 | |
| 4W6841 | 28 HOSE AS | 1 |
