System And Components
459-1525 PANEL GP-CIRCUIT BREAKERS/N LNB1-UP
Group No: 459-1525
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1434456 | 1 INSULATOR | 3 | |
| 3740473 | 2 BAR AS | 1 | |
| 4591530 | 3 PLATE (TOP) | 1 | |
| 4591544 | 4 BRACKET-TERMINAL | 3 | |
| 4692312 | 5 BUS BAR GP-GENERATOR | 1 | |
| 4591539 | TERMINAL | 1 | |
| 4591540 | TERMINAL | 1 | |
| 4591541 | TERMINAL | 1 | |
| 1017396 | 6 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 4 | |
| 2354451 | 7 BOLT-FLANGE HEAD (M6X1X16-MM) | 32 | |
| 4591526 | 8 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 46 | |
| 1471960 | RAIL (30-CM) | ||
| 5621124 | PLATE-BREAKER | 1 | |
| 4591547 | 9 COVER-SIDE | 2 | |
| 5548922 | 10 CIRCUIT BREAKER GP | 1 | |
| 5549949 | 11 BRACKET AS | 1 | |
| 2380029 | INSERT-THREADED (M10X1.5-THD) | 2 | |
| 5549950 | 12 BRACKET AS | 1 | |
| 2380029 | INSERT-THREADED (M10X1.5-THD) | 2 | |
| 5550309 | 13 BUS BAR GP-GENERATOR | 1 | |
| 7H3937 | 14 LOCKWASHER | 6 | |
| 7X2537 | 15 BOLT (M8X1.25X35-MM) | 3 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4199 | 19 BOLT (M8X1.25X12-MM) | 3 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T6466 | 21 BOLT (M10X1.5X60-MM) | 6 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8R8847 | 23 RETAINER-SPRING | 6 | |
| 8T4244 | 24 NUT (M12X1.75-THD) | 3 | |
| 8T4183 | 25 BOLT (M12X1.75X40-MM) | 3 |
