System And Components
523-0521 PANEL GP-CIRCUIT BREAKERS/N LNB1-UP
Group No: 523-0521
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1434456 | 1 INSULATOR | 8 | |
| 3496808 | 2 MOUNT | 8 | |
| 3740473 | 3 BAR AS | 1 | |
| 4591530 | 4 PLATE (TOP) | 1 | |
| 4591547 | 5 COVER-SIDE | 2 | |
| 4690510 | 6 BUS BAR GP-GENERATOR | 4 | |
| 4591536 | TERMINAL | 1 | |
| 4591537 | TERMINAL | 1 | |
| 4591538 | TERMINAL AS | 1 | |
| 4736519 | 7 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 46 | |
| 1471960 | RAIL (30-CM) | ||
| 5230522 | 8 CIRCUIT BREAKER GP (2000-AMPERE) | 1 | |
| 5232160 | 9 BRACKET-TERMINAL | 1 | |
| 5234095 | 10 BRACKET-TERMINAL | 1 | |
| 2354451 | 11 BOLT-FLANGE HEAD (M6X1X16-MM) | 14 | |
| 3429913 | 12 BOLT-FLANGE HEAD (M10X1.5X20-MM) | 2 | |
| 7H3937 | 13 LOCKWASHER | 16 | |
| 7X2537 | 14 BOLT (M8X1.25X35-MM) | 4 | |
| 8R8847 | 15 RETAINER-SPRING | 24 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4199 | 20 BOLT (M8X1.25X12-MM) | 8 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 12 | |
| 8T6466 | 24 BOLT (M10X1.5X60-MM) | 8 | |
| 8T7547 | 25 BOLT (M8X1.25X30-MM) | 4 | |
| 5139221 | 26 SCREW-BUTTON HEAD (M6X1X16-MM) | 12 |
