System And Components
561-8664 PANEL GP-CIRCUIT BREAKERS/N LNB1-UP
Group No: 561-8664
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8413 | 1 STRAP-CABLE (WHITE) | 4 | |
| 3018316 | 2 COVER-END | 1 | |
| 3496808 | 3 MOUNT (HARNESS) | 4 | |
| 3740473 | 4 BAR AS | 1 | |
| 4448242 | 5 SHUNT-TRIP | 1 | |
| 4591530 | 6 PLATE (TOP) | 1 | |
| 8T6466 | 7 BOLT (M10X1.5X60-MM) | 8 | |
| 1017396 | 8 BOLT-SOCKET HEAD (M10X1.5X50-MM) | 4 | |
| 2354451 | 9 BOLT-FLANGE HEAD (M6X1X16-MM) | 26 | |
| 3018313 | 10 BLOCK-TERMINAL (4-TERMINAL) | 20 | |
| 3458835 | 11 BLOCK-TERMINAL | 2 | |
| 3562799 | 12 KIT-MARKER | 1 | |
| 4404396 | 13 ACTUATOR-CIRCUIT BREAKER (30-VOLT) | 1 | |
| 4448241 | 14 SOLENOID (24-VOLT) | 1 | |
| 4591526 | 15 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 46 | |
| 1471960 | RAIL (30-CM) | ||
| 5621124 | PLATE-BREAKER | 1 | |
| 4591547 | 16 COVER-SIDE | 2 | |
| 4702310 | 17 HARNESS AS-PANEL | 1 | |
| 1S9593 | STRAP-CABLE | 15 | |
| 2L8081 | TERMINAL-RING (14-GA TO 16-GA, 1/2-IN SCREW) | 4 | |
| 5579798 | 18 CIRCUIT BREAKER GP (2000-AMPERE) | 1 | |
| 5579799 | 19 BRACKET AS | 1 | |
| 2380029 | INSERT-THREADED (M10X1.5-THD) | 2 | |
| 5579800 | 20 BRACKET AS | 1 | |
| 2380029 | INSERT-THREADED (M10X1.5-THD) | 2 | |
| 5579801 | 21 BUS BAR GP-GENERATOR | 1 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4133 | 23 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 24 BOLT (M10X1.5X20-MM) | 6 | |
| 4702311 | HARNESS AS-PANEL | 1 | |
| 1S9593 | STRAP-CABLE | 15 | |
| 3451120 | CONNECTOR AS | 2 | |
| 3494797 | CONDUIT (4-DM) |
