System And Components
464-8386 WIRING GP-PANELS/N L8D1-UP
Group No: 464-8386
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H4393 | 1 LOCKWASHER | 2 | |
| 5C8312 | 2 NUT (M4X0.7-THD) | 2 | |
| 7X2621 | 3 BOLT (M10X1.5X12-MM) | 1 | |
| 8T4121 | 4 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 9W2275 | 5 RESISTOR (120-OHM) | 1 | |
| 9X8256 | 6 WASHER (6.6X12X2-MM THK) | 2 | |
| 2069512 | 7 CONTACT | 1 | |
| 2145791 | 8 SWITCH AS-ROTARY (REMOTE START) | 1 | |
| 2266446 | 9 SWITCH AS-PUSH BUTTON | 1 | |
| 2615503 | COLLAR | 1 | |
| 2284798 | 10 FILM-IDENTIFICATION (GROUND) | 1 | |
| 2286935 | 11 BLOCK-CONTACT | 1 | |
| 2606682 | 12 RIVET | 8 | |
| 5C2890 | 13 NUT (M6X1-THD) | 2 | |
| 3504303 | 14 GROMMET | 7 | |
| 3562799 | 15 KIT-MARKER | 1 | |
| 3562800 | 16 KIT-MARKER | 1 | |
| 4206320 | 17 FILM-INFORMATION (PANEL IDENTIFICATIONS) | 1 | |
| 4648366 | 18 ENCLOSURE GP-WIRING (STANDARD PANEL) | 1 | |
| 4695569 | 19 HARNESS AS-WIRING | 1 |
