System And Components
526-9489 CIRCUIT BREAKER GPS/N LXK1-UP
Group No: 526-9489
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8413 | 1 STRAP-CABLE (WHITE) | 5 | |
| 2349425 | 2 LINK (TERMINAL) | 2 | |
| 2354451 | 3 BOLT-FLANGE HEAD (M6X1X16-MM) | 13 | |
| 3018313 | 4 BLOCK-TERMINAL (4-TERMINAL) | 20 | |
| 3018316 | 5 COVER-END | 2 | |
| 3458835 | 6 BLOCK-TERMINAL | 2 | |
| 3495641 | 7 PANEL AS-ENCLOSURE | 1 | |
| 3495645 | 8 PANEL-CIRCUIT BREAKER (CLOSING) | 1 | |
| 3495667 | 9 PLATE-COVER (ACCESS) | 1 | |
| 3496808 | 10 MOUNT (HARNESS) | 7 | |
| 3504303 | 11 GROMMET (BLANKING) | 2 | |
| 3562799 | 12 KIT-MARKER | 1 | |
| 3740473 | 13 BAR AS | 1 | |
| 4183227 | 14 RELAY (24-VOLT)(15-AMPERE) | 1 | |
| 4214434 | 15 CONTACTOR (BASIC) | 1 | |
| 3429913 | 16 BOLT-FLANGE HEAD (M10X1.5X20-MM) | 4 | |
| 4702312 | 17 HARNESS AS-PANEL | 1 | |
| 1S9593 | STRAP-CABLE | 6 | |
| 2L8081 | TERMINAL-RING (14-GA TO 16-GA, 1/2-IN SCREW) | 4 | |
| 4784469 | 18 HARNESS AS-PANEL | 1 | |
| 1S9593 | STRAP-CABLE | 3 | |
| 5269501 | 19 CIRCUIT BREAKER GP (800-AMPERE) | 1 | |
| 4702311 | HARNESS AS-PANEL | 1 | |
| 1S9593 | STRAP-CABLE | 15 | |
| 3451120 | CONNECTOR AS | 2 |
