System And Components
370-2569 LINES GP-PARKING BRAKE -REARS/N 9SD1-UP
Group No: 370-2569
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U0423 | 1 VALVE-CHECK (PARKING BRAKE) | 1 | |
| 2V7777 | 2 JUNCTION BLOCK | 1 | |
| 1646877 | 3 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 1716718 | 4 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1057704 | TEE | 1 | |
| 3447389 | 5 SENSOR AS-PRESSURE (PARKING BRAKE OIL) | 1 | |
| 3870148 | 6 HOSE AS | 1 | |
| 3870171 | 7 HOSE AS | 1 | |
| 3917033 | 8 HOSE AS | 1 | |
| 4227384 | 9 HOSE AS | 1 | |
| 4227385 | 10 HOSE AS | 1 | |
| 4227386 | 11 HOSE AS | 1 | |
| 0307942 | 12 ELBOW | 1 | |
| 0307950 | 13 ELBOW | 1 | |
| 0308189 | 14 CONNECTOR | 2 | |
| 0308193 | 15 CONNECTOR | 1 | |
| 0902782 | 16 REDUCER | 1 | |
| 1488407 | 17 PLUG AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 2P1279 | 18 LOCKNUT (9/16-18-THD) | 1 | |
| 2P1314 | 19 CONNECTOR | 2 | |
| 2P7212 | 20 ELBOW-UNION | 1 | |
| 3136235 | 21 VALVE GP-PARKING BRAKE | 1 | |
| 3D2824 | 22 SEAL-O-RING | 3 | |
| 3J1907 | 23 SEAL-O-RING | 6 | |
| 3K0360 | 24 SEAL-O-RING | 2 | |
| 5P3466 | 25 ELBOW (FLARED) | 1 | |
| 5P7468 | 26 CLIP (SLOT) | 2 | |
| 5P7469 | 27 CLIP (TAB) | 2 | |
| 5S7383 | 28 BOLT (3/8-16X1.75-IN) | 2 | |
| 6V0852 | 29 CAP-DUST | 2 | |
| 6V3965 | 30 FITTING (QUICK DISCONNECT) | 2 | |
| 6V4349 | 31 GROMMET | 2 | |
| 7K1181 | 32 STRAP-CABLE | 1 | |
| 7M8485 | 33 SEAL-O-RING | 1 | |
| 8T4121 | 34 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4896 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 8T6408 | 36 BOLT (M10X1.5X160-MM) | 3 | |
| 9S4185 | 37 PLUG (3/4-16-THD) | 1 | |
| 9R3253 | 38 PLATE | 1 | |
| 9B7237 | 39 BOLT (3/8-16X1.25-IN) | 1 | |
| 6V8801 | 40 NUT (3/8-16-THD) | 1 | |
| 4L6454 | 41 BOLT (3/8-16X1-IN) | 1 |
