System And Components
262-4243 PANEL GP-INSTRUMENTS/N K7C579-UP
Group No: 262-4243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C6354 | 1 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 2624621 | 2 HOLDER-FUSE | 4 | |
| 2624623 | 3 FUSE | 3 | |
| 2624622 | 4 FUSE | 1 | |
| 3170082 | 5 LAMP GP-PANEL ILLUMINATION | 2 | |
| 3170081 | 6 RAIL | 1 | |
| 2250547 | 7 BLOCK-TERMINAL | 30 | |
| 1229458 | 8 POTENTIOMETER (1000-OHM) | 1 | |
| 4W5972 | 9 KNOB | 1 | |
| 7C4550 | 10 SEAL (ROTATING SHAFT) | 2 | |
| 9X3994 | 11 PLUG | 2 | |
| 1141142 | 12 CIRCUIT BREAKER AS (10-AMPERE) | 1 | |
| 2236470 | 13 RELAY (10-AMPERE, 24-VOLT) | 1 | |
| 2624255 | 14 BLOCK-TERMINAL | 3 | |
| 1031837 | 15 FILM-CONTROL PANEL (MANUAL STARTING AID) | 1 | |
| 3170087 | 16 STRAP | 2 | |
| 2624648 | 17 RECEPTACLE | 1 | |
| 2624636 | 18 SWITCH | 1 | |
| 2624637 | 19 BLOCK-CONTACT | 4 | |
| 4B2041 | 20 NUT (6-32-THD) | 4 | |
| 4B4863 | 21 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 2143522 | 22 SCREW-MACHINE (6-32X0.75) | 4 | |
| 2624237 | 23 RESISTOR | 1 | |
| 2521732 | 24 BASE-RELAY | 1 | |
| 2110640 | 25 SPRING (RELAY) | 1 | |
| 9X9591 | 26 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED) | 1 | |
| 7E1246 | 27 POTENTIOMETER (2000-OHM) | 1 | |
| 3170083 | 28 RAIL | 1 | |
| 3170084 | 29 GUIDE | 1 | |
| 1338750 | 30 PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 8T8730 | 31 SOCKET-CONNECTOR (16-GA TO 20-GA) | 50 | |
| 9W1951 | 32 RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 8T8729 | 33 PIN-CONNECTOR (16-GA TO 20-GA) | 25 | |
| 5S4245 | 34 SCREW-MACHINE (4-40X0.5-IN) | 4 | |
| 6B4542 | 35 LOCKWASHER | 4 | |
| 6B4540 | 36 NUT (4-40-THD) | 4 | |
| 9X0145 | 37 RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1346258 | CABLE-ELECTRICAL (16-GA)(600-CM) | ||
| 5P5689 | WIRE (8-GA, BLACK)(3-M) | ||
| 3170085 | CONNECTION GP-ELECTRICAL (TERMINAL) | 1 | |
| 3170136 | HOOD | 4 | |
| 3170141 | SLEEVE | 1 | |
| 3170819 | SLEEVE | 1 | |
| 3170086 | FASTENER GP-PANEL | 1 | |
| 0960061 | STRAP-CABLE | 15 | |
| 1715349 | STRAP-MARKER | 40 |
