489-9052 PANEL GP-INSTRUMENTS/N K7C579-UP

Group No: 489-9052

Part Number	Part Name	Qty
2143522	1 SCREW-MACHINE (6-32X0.75)	4
2624621	2 HOLDER-FUSE	4
2624623	3 FUSE (10-AMPERE)	3
2624622	4 FUSE (10-AMPERE)	1
3170082	5 LAMP GP-PANEL ILLUMINATION	2
4247330	6 RAIL	1
3744302	7 BLOCK-TERMINAL	42
4899096	8 TERMINAL AS	1
4898970	9 LABEL-MARKING	2
8C6354	10 CAP-RECEPTACLE (ET CONNECTOR)	1
4B4863	11 WASHER (4.7X11X1.2-MM THK)	4
3708299	12 CIRCUIT BREAKER (240-VOLT)	1
3708300	13 RELAY (24-VOLT)(24-VOLT)	1
2624255	14 BLOCK-TERMINAL	2
1031837	15 FILM-CONTROL PANEL (MANUAL STARTING AID)	1
4B2041	16 NUT (6-32-THD)	4
2624648	17 RECEPTACLE	1
2624636	18 SWITCH (OPERATOR)	1
2624637	19 BLOCK-CONTACT	4
9X3994	20 PLUG	2
3170087	21 STRAP	2
3170084	22 GUIDE	1
2624237	23 RESISTOR	1
3708301	24 BASE-RELAY	1
9X9591	25 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED)	1
7E1246	26 POTENTIOMETER (2000-OHM)	2
3170083	27 RAIL	1
3170826	28 BRACKET-END	2
1338750	29 PLUG AS-CONNECTOR (70-PIN)	1
1599322	SEAL-O-RING	1
8T8730	30 SOCKET-CONNECTOR (16-GA TO 20-GA)	51
9W1951	31 RECEPTACLE AS-CONNECTOR (9-PIN)	1
8T8729	32 PIN-CONNECTOR (16-GA TO 20-GA)	28
6V2480	33 SCREW (4-40X0.5-IN)	4
6B4542	34 LOCKWASHER	4
6B4540	35 NUT (4-40-THD)	4
9X0145	36 RECEPTACLE AS-CONNECTOR (24-PIN)	1
2624244	37 RELAY (24-VOLT)(24-VDC)	1
2666748	38 SWITCH AS-TOGGLE (24-VOLT)	1
6V9492	39 SCREW-MACHINE (M4X0.7X25-MM)	2
7C4550	40 SEAL (ROTATING SHAFT)	2
3170825	41 BOX GP-ELECTRONIC	1
3S2093	STRAP-CABLE	16
1715349	STRAP-MARKER	40
3170085	CONNECTION GP-ELECTRICAL (TERMINAL)	1
3170086	FASTENER GP-PANEL	1
