System And Components
393-0292 LINES GP-RIDE CONTROL -1-PIECE, SMART BOOMS/N K5E1-UP
Group No: 393-0292 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1949390 | 1 CLAMP GP-HYDRAULIC LINES | 2 | |
| 1949388 | CLAMP | 2 | |
| 1949389 | PLATE | 1 | |
| 2957687 | 2 VALVE GP-SOLENOID (RIDE CONTROL, VA BOOM) | 1 | |
| 2957688 | 3 VALVE GP-SOLENOID (RIDE CONTROL, HEAD END, LH) | 1 | |
| 2957689 | 4 VALVE GP-SOLENOID (RIDE CONTROL, HEAD END, RH) | 1 | |
| 2958554 | 5 BLOCK | 1 | |
| 2993655 | 6 CLAMP | 2 | |
| 3055897 | 7 SPACER | 2 | |
| 3105052 | 8 HOSE AS | 1 | |
| 1017403 | 9 BOLT-SOCKET HEAD (M10X1.5X80-MM) | 8 | |
| 1488341 | 10 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536256 | 11 ELBOW AS | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 1646872 | 12 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1158634 | TEE-O-RING | 1 | |
| 1980143 | 13 ELBOW AS | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1572348 | ELBOW | 1 | |
| 2717649 | 14 BOLT (M10X1.5X95-MM) | 2 | |
| 2939452 | 15 MOUNTING-CABLE TIE | 1 | |
| 8T6685 | 16 BOLT (M10X1.5X110-MM) | 2 | |
| 8T3844 | 17 BOLT (M6X1X70-MM) | 3 | |
| 8T6974 | 18 BOLT (M6X1X80-MM) | 1 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 1 | |
| 3403267 | 20 ACCUMULATOR GP (CHARGED) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 1 |
