System And Components
422-7120 LINES GP-BLADE -MATERIAL HANDLERS/N P9M1-UP
Group No: 422-7120
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1383394 | 1 HOSE AS | 1 | |
| 1939063 | 2 SWITCH AS-ROCKER (LEFT STABILIZER) | 2 | |
| 1939064 | 3 SWITCH AS-ROCKER (RIGHT STABILIZER) | 2 | |
| 1117899 | GASKET | 1 | |
| 1946989 | 4 ORIFICE | 4 | |
| 1967543 | 5 VALVE GP-SOLENOID (24-VOLT)(STABILIZER) | 2 | |
| 2250554 | 6 HOSE AS | 1 | |
| 2465874 | 7 HOSE AS | 1 | |
| 4521545 | 8 HOSE AS | 1 | |
| 2916475 | 9 VALVE GP-SOLENOID (BLADE LOCKOUT) | 1 | |
| 2916496 | 10 PLATE | 1 | |
| 3375851 | 11 BLOCK | 2 | |
| 4521546 | 12 HOSE AS | 1 | |
| 4501880 | 13 HOSE AS | 1 | |
| 3595080 | 14 BLOCK-MANIFOLD | 2 | |
| 4521547 | 15 HOSE AS | 1 | |
| 3595087 | 16 ADAPTER AS | 8 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3595079 | ADAPTER | 1 | |
| 1293181 | 17 BOLT-SOCKET HEAD (M10X1.5X55-MM) | 8 | |
| 1488318 | 18 CONNECTOR AS | 9 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488336 | 19 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488363 | 20 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488365 | 21 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488367 | 22 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488374 | 23 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488378 | 24 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488395 | 25 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 1488415 | 26 REDUCER AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8936 | REDUCER | 1 | |
| 1488433 | 27 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488436 | 28 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 1488444 | 29 TEE AS-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1557329 | 30 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5H8853 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1645624 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 9X2085 | ELBOW | 1 | |
| 2042281 | 32 STRAP-CABLE | 2 | |
| 2062423 | 33 SADDLE-MOUNTING | 2 | |
| 2098296 | 34 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 2 | |
| 2986020 | 35 BOLT-SOCKET HEAD (M8X1.25X60-MM) | 4 | |
| 4I9521 | 36 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 37 BAND-MARKER (YELLOW, L2) | 2 | |
| 4J5267 | 38 SEAL-O-RING | 2 | |
| 7K1181 | 39 STRAP-CABLE | 4 | |
| 7X2534 | 40 BOLT (M6X1X50-MM) | 4 | |
| 8T3647 | 41 BOLT (M8X1.25X80-MM) | 2 | |
| 4501336 | 42 HOSE AS | 4 | |
| 2007500 | 43 HOSE AS | 2 | |
| 4501915 | 44 HOSE AS | 2 | |
| 4501851 | 45 HOSE AS | 4 |
