System And Components
Assembly
100%

416-2229 ENCLOSURE GP-GENERATORS/N NAP1-UP

Group No: 416-2229
Part NumberPart NameQty
39324521 PANEL AS6
39324752 PANEL AS3
1338073HANDHOLD1
39324833 CHANNEL2
39324844 DUCT AS2
1428194RIVET21
3932485PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
41620485 PANEL AS1
41620496 PANEL1
41620527 PANEL AS1
2380029INSERT-THREADED (M10X1.5-THD)6
41620538 PANEL AS1
2380029INSERT-THREADED (M10X1.5-THD)6
41620559 PANEL AS1
2662789HANDLE2
416205610 PANEL2
416205711 PANEL1
416205812 PANEL1
416205913 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)6
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)8
416206014 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)6
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)11
416206215 BRACKET1
416206516 BRACKET1
416206817 PANEL1
416206918 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
416207019 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
416207120 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)10
416207221 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)6
416207322 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)6
416207423 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)6
416207624 DOOR AS6
416207725 PANEL4
416207826 PANEL AS2
8T3490NUT-WELD (M10X1.5-THD)1
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)8
416207927 PANEL AS2
8T3490NUT-WELD (M10X1.5-THD)1
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)8
422606928 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)4
422607029 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)4
