453-2117 PANEL GP-ENCLOSURES/N NAP1-UP

Group No: 453-2117
Part NumberPart NameQty
14471831 RING-RETAINING15
25148892 WASHER-HARD (7.2X14.5X2-MM THK)14
45320683 PANEL AS2
14281943A RIVET4
14282123B BRACKET2
45321133C PANEL AS1
45320754 PANEL2
45320765 PANEL3
45320806 PANEL AS (RH)1
14281946A RIVET4
14282126B BRACKET2
45320966C PANEL AS1
45320897 DUCT AS1
14281947A RIVET21
45320998 PANEL AS (RH)1
45321519 PANEL AS (RH)1
23800299A INSERT-THREADED (M10X1.5-THD)3
099641810 NUT (M6X1-THD)14
340153011 BOLT-FLANGE HEAD (M6X1X18-MM)14
344567512 NUT (M10X1.5-THD)36
8T412113 WASHER-HARD (11X21X2.5-MM THK)72
8T413614 BOLT (M10X1.5X25-MM)36
6V029215 PLUG2
390319016 PLUG (SNAP)4
