System And Components
416-2047 MUFFLER GPS/N NAW1-UP
Group No: 416-2047
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L3773 | 1 GASKET-EXHAUST ELBOW | 1 | |
| 1139848 | 2 GASKET | 3 | |
| 1255700 | 3 CAP AS-RAIN (EXHAUST) | 1 | |
| 2111009 | 4 ADAPTER AS | 1 | |
| 2353324 | 5 PIPE AS | 1 | |
| 2436277 | 6 MUFFLER AS | 1 | |
| 4166480 | 7 BRACKET AS | 2 | |
| 4166481 | STRAP-MUFFLER | 1 | |
| 4166482 | 9 TUBE AS | 1 | |
| 5S7383 | 10 BOLT (3/8-16X1.75-IN) | 8 | |
| 6V8801 | 11 NUT (3/8-16-THD) | 8 | |
| 7X2563 | 12 BOLT (M20X2.5X60-MM) | 24 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4123 | 14 WASHER (22X35X3.5-MM THK) | 48 | |
| 8T4131 | 15 NUT (M20X2.5-THD) | 24 | |
| 8T4186 | 16 BOLT (M10X1.5X40-MM) | 12 | |
| 8T4194 | 17 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4244 | 19 NUT (M12X1.75-THD) | 4 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 |
