System And Components
453-2166 ENCLOSURE GP-GENERATORS/N NAW1-UP
Group No: 453-2166
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E4096 | 1 CAP | 2 | |
| 4P1991 | 2 BUTTON | 18 | |
| 1349925 | 3 HOLDER | 6 | |
| 1426950 | 4 HINGE AS | 12 | |
| 1428194 | 5 RIVET | 68 | |
| 1447183 | 6 RING-RETAINING | 24 | |
| 2514889 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 3079598 | 8 COVER-ACCESS | 1 | |
| 3082674 | 9 PAWL | 6 | |
| 3522979 | 10 LATCH AS | 6 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 1608499 | NUT (M12X1.5-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3660083 | 11 BRACKET AS | 6 | |
| 3904895 | 12 SHIELD | 3 | |
| 3991299 | 13 SHIELD AS | 1 | |
| 4226062 | 14 WIRE AS | 6 | |
| 5W9297 | TERMINAL | 2 | |
| 4449542 | 15 SHIELD | 1 | |
| 4532167 | 16 ENCLOSURE GP-GENERATOR | 1 | |
| 4532171 | 17 INSULATION GP-HEAT | 1 | |
| 0996418 | 18 NUT (M6X1-THD) | 40 | |
| 1424901 | 19 SCREW (M10X1.5X20-MM) | 60 | |
| 3401530 | 20 BOLT-FLANGE HEAD (M6X1X18-MM) | 36 | |
| 3987367 | 21 SEAL (45-DM EACH) |
