System And Components
453-2119 PANEL GP-ENCLOSURES/N NAW1-UP
Group No: 453-2119
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1447183 | 1 RING-RETAINING | 18 | |
| 4183985 | 2 BRACKET | 2 | |
| 4532079 | 3 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 6 | |
| 4532084 | 4 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 6 | |
| 4532086 | 5 PANEL AS | 3 | |
| 4532120 | 6 PANEL AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4532121 | 7 PANEL AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4532123 | 8 PANEL AS (RH) | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 4532124 | 9 PANEL AS | 1 | |
| 4532125 | 10 PANEL AS (LH) | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 4532126 | 11 PANEL AS (RH) | 1 | |
| 4532127 | 12 PANEL AS (CENTER) | 1 | |
| 4532128 | 13 PANEL AS (LH) | 1 | |
| 0996418 | 14 NUT (M6X1-THD) | 12 | |
| 3401530 | 15 BOLT-FLANGE HEAD (M6X1X18-MM) | 38 | |
| 8T6936 | 16 SEAL (0.6-M) | ||
| 8T6936 | 16A SEAL (0.025-M EACH) | ||
| 2514889 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 8 |
