Assembly
100%

453-2168 PANEL GP-ENCLOSURES/N NAW1-UP

Group No: 453-2168
Part NumberPart NameQty
14249011 SCREW (M10X1.5X20-MM)12
14471832 RING-RETAINING23
25148893 WASHER-HARD (7.2X14.5X2-MM THK)16
45320754 PANEL2
45320765 PANEL3
45320786 PANEL AS (LH)1
2380029INSERT-THREADED (M10X1.5-THD)15
4532094PANEL AS (LH)1
45320877 PANEL AS1
1338073HANDHOLD1
4532103PANEL AS1
45320898 DUCT AS1
1428194RIVET21
45320909 PANEL AS2
1428194RIVET4
1428212BRACKET2
4532110PANEL AS1
453210110 PANEL AS (LH)1
453217711 PANEL AS (LH)1
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)2
4532186PANEL AS (LH)1
099641812 NUT (M6X1-THD)14
340153013 BOLT-FLANGE HEAD (M6X1X18-MM)14
344567514 NUT (M10X1.5-THD)36
8T412115 WASHER-HARD (11X21X2.5-MM THK)72
8T413616 BOLT (M10X1.5X25-MM)36
390319017 PLUG6
