Assembly
100%

453-2169 PANEL GP-ENCLOSURES/N NAW1-UP

Group No: 453-2169
Part NumberPart NameQty
14471831 RING-RETAINING18
25148892 WASHER-HARD (7.2X14.5X2-MM THK)16
45320683 PANEL AS2
1428194RIVET4
1428212BRACKET2
4532113PANEL AS1
45320754 PANEL2
45320765 PANEL3
45320896 DUCT AS1
1428194RIVET21
8T41367 BOLT (M10X1.5X25-MM)36
45320998 PANEL AS (RH)1
45321769 PANEL AS (RH)1
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)2
4532185PANEL AS (RH)1
099641810 NUT (M6X1-THD)14
340153011 BOLT-FLANGE HEAD (M6X1X18-MM)14
344567512 NUT (M10X1.5-THD)36
8T412113 WASHER-HARD (11X21X2.5-MM THK)72
390319014 PLUG4
6V029215 PLUG2
453209316 PANEL AS (RH)1
