System And Components
354-6491 RADIATOR GPS/N NH41-UP
Group No: 354-6491
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2620489 | 1 CLAMP | 1 | |
| 4251132 | 2 ADAPTER | 1 | |
| 7K1181 | 3 STRAP-CABLE | 2 | |
| 8N2807 | 4 HOSE | 2 | |
| 8T4985 | 5 CLAMP-HOSE | 4 | |
| 9U6998 | 6 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3E4041 | ELBOW | 1 | |
| 9X2201 | 7 CLAMP-HOSE | 4 | |
| 1089656 | 8 STRAP-CABLE | 2 | |
| 1270929 | 9 CLAMP-V BAND | 2 | |
| 2647111 | 10 HOSE | 1 | |
| 2647112 | 11 HOSE | 3 | |
| 3065412 | 12 HOSE | 2 | |
| 4389293 | 13 STRAP | 3 | |
| 3546463 | 14 FAN GP-BLOWER | 1 | |
| 3546485 | 15 TUBE AS | 1 | |
| 3546486 | 16 TUBE | 1 | |
| 3546488 | 17 TUBE AS | 1 | |
| 3546489 | 18 TUBE AS | 1 | |
| 4500101 | 19 GUARD GP-FAN | 1 | |
| 3660080 | 20 RADIATOR GP | 1 | |
| 3842242 | 21 TUBE AS | 1 | |
| 3842243 | 22 BRACKET | 1 | |
| 1440367 | 23 CLAMP-HOSE | 6 | |
| 1757141 | 24 NUT-HEX FLANGE (M10X1.5-THD) | 4 | |
| 3383669 | 25 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 4 | |
| 1488312 | 26 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3T4965 | ADAPTER | 1 | |
| 3429913 | 27 BOLT-FLANGE HEAD (M10X1.5X20-MM) | 7 | |
| 3B7764 | 28 BUSHING (REDUCING) | 1 | |
| 8C3089 | 30 SEAL-O-RING | 2 | |
| 8T4984 | 31 CLAMP-HOSE | 2 | |
| 9M7958 | 32 CLAMP-HOSE | 2 | |
| 3718094 | 33 HOSE (136-CM) |
