526-9503 PANEL GP-CIRCUIT BREAKERS/N CE31-UP; NH31-UP

Group No: 526-9503

Part Number	Part Name	Qty
1434456	1 INSULATOR	8
3018313	2 BLOCK-TERMINAL (4-TERMINAL)	20
3018316	3 COVER-END	1
3458835	4 BLOCK-TERMINAL	2
3496808	5 MOUNT	8
3562799	6 KIT-MARKER	1
3740473	7 BAR AS	1
4591530	8 PLATE (TOP)	1
4591543	9 BRACKET-TERMINAL	1
4591544	10 BRACKET-TERMINAL	2
4591547	11 COVER-SIDE	2
4702310	12 HARNESS AS-PANEL	1
1S9593	STRAP-CABLE	15
2L8081	TERMINAL-RING (14-GA TO 16-GA, 1/2-IN SCREW)	4
4690510	13 BUS BAR GP-GENERATOR	3
4591536	TERMINAL	1
4591537	TERMINAL	1
4591538	TERMINAL AS	1
4690521	14 CIRCUIT BREAKER GP (2000-AMPERE, 3-POLE)	1
4692312	15 BUS BAR GP-GENERATOR	1
4591539	TERMINAL	1
4591540	TERMINAL	1
4591541	TERMINAL	1
4694063	16 BRACKET-TERMINAL	1
4736519	17 PANEL AS	1
3E4304	INSERT-THREADED (M6X1-THD)	46
1471960	RAIL (30-CM)
2354451	19 BOLT-FLANGE HEAD (M6X1X16-MM)	18
3429913	20 BOLT-FLANGE HEAD (M10X1.5X20-MM)	2
4404396	21 ACTUATOR-CIRCUIT BREAKER	1
4448241	22 SOLENOID (24-VOLT)(CIRCUIT BREAKER)	1
7H3937	23 LOCKWASHER	16
7X2537	24 BOLT (M8X1.25X35-MM)	5
8L8413	25 STRAP-CABLE (WHITE)	4
8R8847	26 RETAINER-SPRING	24
8T4121	27 WASHER-HARD (11X21X2.5-MM THK)	16
8T4133	28 NUT (M10X1.5-THD)	4
8T4137	29 BOLT (M10X1.5X20-MM)	6
8T4183	30 BOLT (M12X1.75X40-MM)	12
8T4199	31 BOLT (M8X1.25X12-MM)	8
8T4223	32 WASHER-HARD (13.5X25.5X3-MM THK)	24
8T4224	33 WASHER-HARD (8.8X16X2-MM THK)	16
8T4244	34 NUT (M12X1.75-THD)	12
8T6466	35 BOLT (M10X1.5X60-MM)	6
8T7547	36 BOLT (M8X1.25X30-MM)	3
5139221	37 SCREW-BUTTON HEAD (M6X1X16-MM)	12
4702311	HARNESS AS-PANEL	1
3494797	CONDUIT (4-DM)
1S9593	STRAP-CABLE	15
3451120	CONNECTOR AS	2
4448242	SHUNT-TRIP	1
