394-9050 ENCLOSURE GP-GENERATORS/N NH41-UP

Group No: 394-9050
Part NumberPart NameQty
4P19911 BUTTON10
8C44132 BALL JOINT5
14248993 LOCKWASHER40
14269504 HINGE AS10
14281945 RIVET42
14471836 RING-RETAINING45
20411167 HANDLE1
26066958 SCREW-FLAT HEAD (M6X1X25-MM)4
21439669 NUT (M6X1-THD)24
219735010 STAY5
232494411 GROMMET3
235445112 BOLT-FLANGE HEAD (M6X1X16-MM)20
265711113 WINDOW1
329243114 POST-CORNER4
346550415 CLIP48
347402516 HATCH1
362046617 PLUG5
366008118 LATCH AS5
5C2890NUT (M6X1-THD)4
1H3244LOCKWASHER4
8T4244NUT (M12X1.75-THD)2
3260612WASHER-TAB2
366008219 PAWL5
366008320 BRACKET AS5
366008421 POST-SIDE4
369881022 ENCLOSURE GP-GENERATOR1
394905123 INSULATION GP-GENERATOR1
142490124 SCREW (M10X1.5X20-MM)122
338366925 BOLT-FLANGE HEAD (M10X1.5X30-MM)84
5C726126 NUT (M8X1.25-THD)10
5P411627 WASHER-HARD (8.8X20.5X2-MM THK)10
7X255228 BOLT (M16X2X30-MM)4
9X825729 WASHER (17.5X30X3.5-MM THK)4
237507130 SEAL (19-DM)
237507231 SEAL (19-DM)
197803933 SEAL (44.5-DM EACH)
197803933A SEAL (48.7-DM)
515738134 GROMMET1
351719935 SEAL-FOAM (52-DM EACH)
351719935A SEAL-FOAM (0.5-DM EACH)
351719935B SEAL-FOAM (18-DM EACH)
351719935C SEAL-FOAM (2.3-DM EACH)
351719935D SEAL-FOAM (2.5-DM EACH)
351719935E SEAL-FOAM (6-DM EACH)
351719935F SEAL-FOAM (17.4-DM)
351719935G SEAL-FOAM (3.2-DM)
351719935H SEAL-FOAM (4.6-DM)
351719935J SEAL-FOAM (1.2-DM)
354388236 SEAL (20-DM EACH)
