System And Components
476-4920 ENCLOSURE GP-GENSETS/N GB31-UP
Group No: 476-4920
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4820351 | 1 WASHER | 26 | |
| 4854756 | 2 PANEL AS | 1 | |
| 4854757 | 3 PANEL AS-SOUND SUPPRESSION | 5 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 2983887 | INSULATION-SOUND SUPPRESSION (4-M) | ||
| 2983888 | INSULATION (2-M) | ||
| 7X7926 | RIVET | 30 | |
| 4854758 | 4 PANEL AS | 1 | |
| 4854759 | 5 PANEL AS | 1 | |
| 4854760 | 6 PANEL AS | 1 | |
| 4854761 | 7 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4854762 | 8 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 8 | |
| 4854763 | 9 FRAME AS-DOOR | 1 | |
| 7X7926 | RIVET | 8 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3358548 | SEAL (10-M) | ||
| 4854764 | 10 FRAME AS-DOOR | 1 | |
| 7X7926 | RIVET | 8 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3358548 | SEAL (5-M) | ||
| 4854765 | 11 FRAME AS-DOOR | 1 | |
| 7X7926 | RIVET | 8 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3358548 | SEAL (5-M) | ||
| 4854766 | 12 FRAME AS-DOOR | 1 | |
| 7X7926 | RIVET | 8 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3358548 | SEAL (10-M) | ||
| 4854767 | 13 DOOR GP-ACCESS | 2 | |
| 4854768 | 14 DOOR GP-ACCESS | 1 | |
| 4854769 | 15 DOOR GP-ACCESS | 1 | |
| 4854770 | 16 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 14 | |
| 4854771 | 17 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 14 | |
| 4854772 | 18 PANEL AS (LH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4854773 | 19 PANEL AS (RH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4854774 | 20 PANEL AS | 1 | |
| 4854775 | 21 PANEL AS | 1 | |
| 4854776 | 22 PANEL AS | 1 | |
| 4854777 | 23 BRACKET AS | 1 | |
| 4854778 | 24 PANEL AS-ROOF | 1 | |
| 4854779 | 25 PANEL AS-ROOF | 1 | |
| 4854780 | 26 PANEL AS-ROOF | 1 | |
| 4854781 | 27 PANEL AS-ROOF | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4908 | BOLT (M8X1.25X25-MM) | 2 | |
| 3445674 | NUT (M8X1.25-THD) | 2 | |
| 4854782 | 28 PANEL AS-ROOF | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4136 | BOLT (M10X1.5X25-MM) | 8 | |
| 3445675 | NUT (M10X1.5-THD) | 8 | |
| 4854783 | 29 BRACKET AS | 1 | |
| 4854784 | 30 BRACKET AS | 1 | |
| 4854785 | 31 BRACKET AS | 4 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | BOLT (M10X1.5X25-MM) | 4 | |
| 3445675 | NUT (M10X1.5-THD) | 4 | |
| 4854786 | 32 PANEL AS-SOUND SUPPRESSION | 6 | |
| 7X7926 | RIVET | 30 | |
| 2983887 | INSULATION-SOUND SUPPRESSION (4-M) | ||
| 2983888 | INSULATION (2-M) | ||
| 4854787 | 33 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 12 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 8T4908 | BOLT (M8X1.25X25-MM) | 12 | |
| 4854788 | 34 PANEL AS | 1 | |
| 4854790 | 35 BRACKET | 2 | |
| 3445674 | 36 NUT (M8X1.25-THD) | 98 | |
| 3445675 | 37 NUT (M10X1.5-THD) | 104 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 228 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 124 | |
| 8T4195 | 40 BOLT (M10X1.5X30-MM) | 26 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 234 | |
| 8T4908 | 42 BOLT (M8X1.25X25-MM) | 136 | |
| 4820352 | SEAL (65-M) | ||
| 2983888 | INSULATION (73-M) | ||
| 2983887 | INSULATION-SOUND SUPPRESSION (75-M) |
