426-3910 BOX GP-CONTROL PANEL -EMCPS/N GB31-UP

Group No: 426-3910

Part Number	Part Name	Qty
4333127	1 BOX GP-CONTROL PANEL	1
4247330	2 RAIL	2
3170826	3 BRACKET-END	4
4236803	4 TERMINAL	2
2624237	5 RESISTOR	2
4247329	6 COVER-END	5
3744302	7 BLOCK-TERMINAL	52
3170817	8 TERMINAL AS	118
3708298	9 CIRCUIT BREAKER (240-VOLT)	1
3708299	10 CIRCUIT BREAKER (240-VOLT)	1
4246661	11 CIRCUIT BREAKER	1
3170102	12 TERMINAL AS	24
4242965	13 HOLDER-FUSE	5
2624622	14 FUSE (10-AMPERE)	1
2624255	15 BLOCK-TERMINAL	3
2624623	16 FUSE (10-AMPERE)	4
3847461	17 FUSE (10-AMPERE)	1
3847463	18 FUSE (10-AMPERE)	1
8T4205	19 WASHER-HARD (7.2X14.5X2-MM THK)	4
6A9083	20 SCREW-MACHINE (M6X1X15-MM)	4
2624301	21 SWITCH AS (SOLENOID)	1
8T0328	22 WASHER-HARD (5.5X10X1-MM THK)	6
5C5301	23 SCREW-MACHINE	6
3170139	24 TERMINAL AS	2
3170132	25 TERMINAL AS	2
3708302	26 RELAY (24-VOLT)(24-VOLT, 35-AMPERE)	1
0965962	27 WASHER-HARD (3.4X7X0.8-MM THK)	1
8T0265	28 SCREW-MACHINE (M3X0.5X16-MM)	1
3170103	29 TERMINAL AS	4
3170136	30 HOOD	4
3170084	31 GUIDE	2
9W1951	32 RECEPTACLE AS-CONNECTOR (9-PIN)	1
8T8729	33 PIN-CONNECTOR (16-GA TO 20-GA)	9
8C6354	34 CAP-RECEPTACLE (ET CONNECTOR)	1
6B4542	35 LOCKWASHER	4
5S4245	36 SCREW-MACHINE (4-40X0.5-IN)	4
6B4540	37 NUT (4-40-THD)	4
1550950	38 FILM-IDENTIFICATION (GENERATOR CONTROL PANEL)	1
5C8312	39 NUT (M4X0.7-THD)	2
1607689	40 PLUG AS-CONNECTOR (70-PIN)	1
1599322	SEAL-O-RING	1
8T8730	41 SOCKET-CONNECTOR (16-GA TO 20-GA)	40
2672937	42 FILM-IDENTIFICATION (PANEL)	1
2624636	43 SWITCH (OPERATOR)	1
3170130	44 TERMINAL AS	12
2624637	45 BLOCK-CONTACT	1
2624638	46 BLOCK-CONTACT	2
3930817	47 SWITCH-SELECTOR	2
9X3994	48 PLUG	2
3057964	49 MAGNET	1
3S2093	50 STRAP-CABLE	50
2L8076	51 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	4
4370497	52 CABLE (70-DM)
