System And Components
419-5807 DOOR AS-ACCESS -LHS/N GB31-UP
Group No: 419-5807
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3358548 | 1 SEAL (6-M) | ||
| 7X7926 | 2 RIVET | 54 | |
| 2984472 | 3 LOCK (LH) | 1 | |
| 2984473 | 4 HANDLE AS-DOOR | 1 | |
| 3507417 | KEY-HANDLE | 1 | |
| 3507514 | HANDLE-DOOR | 1 | |
| 2983929 | 5 RETAINER (244-CM) | ||
| 9X8267 | 6 WASHER (6.6X12X2-MM THK) | 6 | |
| 7J5925 | 7 PIN-COTTER | 2 | |
| 2985133 | 8 HANDLE-DOOR | 1 | |
| 6V8214 | 9 BOLT (M6X1X20-MM) | 6 | |
| 1199453 | 10 SCREW (M6X1X16-MM) | 2 | |
| 0950756 | 11 SCREW-MACHINE (M5X0.8X16-MM) | 2 | |
| 3825741 | 12 HOLDER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 3825743 | BRACKET-MOUNTING | 1 | |
| 4195806 | 13 GLASS-WINDOW | 1 |
