System And Components
424-2074 ENCLOSURE GP-GENERATORS/N DH41-UP
Group No: 424-2074
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P1991 | 1 BUTTON | 10 | |
| 8C4413 | 2 BALL JOINT | 5 | |
| 1424899 | 3 LOCKWASHER | 40 | |
| 1426950 | 4 HINGE AS | 10 | |
| 1428194 | 5 RIVET | 30 | |
| 1447183 | 6 RING-RETAINING | 46 | |
| 2041116 | 7 HANDLE | 1 | |
| 2606695 | 8 SCREW-FLAT HEAD (M6X1X25-MM) | 4 | |
| 2143966 | 9 NUT (M6X1-THD) | 24 | |
| 2197350 | 10 STAY | 5 | |
| 2324944 | 11 GROMMET | 3 | |
| 2354451 | 12 BOLT-FLANGE HEAD (M6X1X16-MM) | 20 | |
| 2657111 | 13 WINDOW | 1 | |
| 3292431 | 14 POST-CORNER | 4 | |
| 3465504 | 15 CLIP | 48 | |
| 3474025 | 16 HATCH | 1 | |
| 3620466 | 17 PLUG (13.6X35X16-MM THK) | 5 | |
| 3660075 | 18 INSULATION GP-GENERATOR | 1 | |
| 3660081 | 19 LATCH AS | 5 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 8T4244 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3660082 | 20 PAWL | 5 | |
| 3660083 | 21 BRACKET AS | 5 | |
| 3660084 | 22 POST-SIDE | 4 | |
| 4242071 | 23 ENCLOSURE GP-GENERATOR | 1 | |
| 1424901 | 24 SCREW (M10X1.5X20-MM) | 116 | |
| 3383669 | 25 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 77 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 10 | |
| 5P4116 | 27 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 7X2552 | 28 BOLT (M16X2X30-MM) | 4 | |
| 9X8257 | 29 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 2375071 | 30 SEAL (19-DM) | ||
| 2375072 | 31 SEAL (19-DM) | ||
| 3543882 | 32 SEAL (17.2-DM EACH) | ||
| 1978039 | 33 SEAL (44.5-DM EACH) | ||
| 1978039 | 33A SEAL (47.3-DM) | ||
| 3517199 | 34 SEAL-FOAM (15-DM EACH) | ||
| 3517199 | 34A SEAL-FOAM (0.5-DM EACH) | ||
| 3517199 | 34B SEAL-FOAM (48.1-DM EACH) | ||
| 3517199 | 34C SEAL-FOAM (2.3-DM EACH) | ||
| 3517199 | 34D SEAL-FOAM (4.7-DM) | ||
| 3517199 | 34E SEAL-FOAM (2.45-DM EACH) | ||
| 3517199 | 34F SEAL-FOAM (4.6-DM EACH) | ||
| 3517199 | 34G SEAL-FOAM (1.2-DM EACH) | ||
| 5157381 | 35 GROMMET | 1 |
