Assembly
100%

384-2920 INSULATION GP-HEATS/N KMR1-UP; TMY1-UP; HTZ1-UP

Group No: 384-2920
Part NumberPart NameQty
37832161 BRACKET AS4
6V9632NUT-WELD (M6X1-THD)2
8T3612NUT-WELD (M8X1.25-THD)1
38429212 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)2
38429223 SHIELD-HEAT1
38429234 SHIELD-HEAT1
38429245 SHIELD-HEAT1
38429266 SHIELD-HEAT1
38429277 SHIELD-HEAT1
38429288 SHIELD-HEAT1
38429419 SHIELD-HEAT1
384294210 SHIELD-HEAT1
394502811 SHIELD-HEAT1
394502912 SHIELD-HEAT1
448034113 SHIELD-HEAT1
448034214 SHIELD-HEAT1
8T686915 BOLT (M8X1.25X60-MM)4
8T422416 WASHER-HARD (8.8X16X2-MM THK)4
319351517 BOLT-FLANGE HEAD (M6X1X10-MM)62
358552218 BOLT-FLANGE HEAD (M6X1X25-MM)10
