System And Components
428-8778 VALVE GP-AIR CONTROLS/N KMR1-UP; TMY1-UP; HTZ1-UP
Group No: 428-8778
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3462003 | 1 ELBOW | 1 | |
| 3653006 | 2 VALVE GP-AIR CONTROL | 1 | |
| 3855773 | 3 CONNECTOR AS | 1 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3893708 | 4 PLUG AS | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 4152405 | 5 MANIFOLD GP-INLET | 1 | |
| 4152415 | 6 HOSE-AIR | 1 | |
| 4164685 | 7 PLATE | 1 | |
| 4288779 | 8 TUBE AS | 1 | |
| 4288780 | 9 ELBOW-AIR INLET | 1 | |
| 1246275 | 10 CLAMP-HOSE | 2 | |
| 1984775 | 11 WASHER-HARD (6.6X15X6-MM THK) | 4 | |
| 8T6869 | 12 BOLT (M8X1.25X60-MM) | 2 | |
| 3072671 | 13 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 3139614 | 15 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 7X2538 | 16 BOLT (M8X1.25X100-MM) | 4 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T4971 | 18 BOLT (M6X1X30-MM) | 2 | |
| 7X2533 | 19 BOLT (M6X1X35-MM) | 2 |
