System And Components
380-8315 LINES GP-FUELS/N KMR1-403; TMY1-286; HTZ1-336
Group No: 380-8315
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1243019 | 1 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2311345 | 2 BRACKET AS | 1 | |
| 8T5413 | STUD-WELD (M10X1.5X25-MM) | 1 | |
| 3328598 | 3 ADAPTER AS | 1 | |
| 0343679 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3498519 | 4 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3510263 | 5 VALVE-BALL | 1 | |
| 3510265 | 6 VALVE-BALL | 1 | |
| 3824068 | 7 HOSE AS | 1 | |
| 3824288 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4475602 | 9 BRACKET AS | 1 | |
| 4508105 | 10 HOSE AS | 1 | |
| 4529531 | 11 TUBE AS | 1 | |
| 0919035 | 12 SPACER (11X25X20-MM THK) | 1 | |
| 1591503 | 13 CLAMP-HOSE | 1 | |
| 1759079 | 14 ROD-LINK | 1 | |
| 1803998 | 15 STUD (M10X1.5X55-MM) | 1 | |
| 1K4649 | 16 SPACER (0.516X1X1-IN THK) | 1 | |
| 1P4278 | 17 CLAMP-HOSE | 1 | |
| 1S0996 | 18 CLIP | 1 | |
| 2287090 | 19 SEAL-O-RING | 1 | |
| 2385080 | 20 SEAL-O-RING | 3 | |
| 3196225 | 21 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218632 | 22 CONNECTOR AS | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3445675 | 23 NUT (M10X1.5-THD) | 3 | |
| 5C7261 | 24 NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 25 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 5P9299 | 26 CLIP (LOOP) | 2 | |
| 6D4244 | 27 CLIP (LOOP) | 4 | |
| 6D4247 | 28 CLIP | 5 | |
| 7X7729 | 29 WASHER (11X25X3-MM THK) | 1 | |
| 8T0119 | 30 ELBOW | 1 | |
| 8T1887 | 31 CLIP (SLOT) | 1 | |
| 8T1888 | 32 CLIP (TAB) | 1 | |
| 8T1891 | 33 CLIP (SLOT) | 1 | |
| 8T1892 | 34 CLIP (TAB) | 1 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 36 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 37 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4177 | 38 BOLT (M8X1.25X90-MM) | 1 | |
| 8T4179 | 39 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4182 | 40 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4195 | 41 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4172 | 42 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8W1253 | 45 SPACER (11.06X15.88X60-MM THK) | 1 | |
| 5P5991 | 46 HOSE (0.4-M) | ||
| 4231983 | 47 HOSE (35-IN) | ||
| 8T7934 | 48 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 4I7889 | 49 SPACER (11X25X45-MM THK) | 1 |
