System And Components
380-8315 LINES GP-FUELS/N KMR496-542; TMY327-338; HTZ517-610
Group No: 380-8315
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T0119 | 1 ELBOW | 1 | |
| 1243019 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2311345 | 3 BRACKET AS | 1 | |
| 3353976 | 4 ELBOW AS | 1 | |
| 8T0119 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3498519 | 5 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3510265 | 6 VALVE-BALL | 1 | |
| 3545137 | 7 SPACER (11X25X25-MM THK) | 1 | |
| 3824288 | 8 BRACKET AS | 1 | |
| 3893724 | 9 VALVE AS-BALL | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3510263 | VALVE-BALL | 1 | |
| 3960382 | 10 ELBOW AS | 1 | |
| 6V4292 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4475602 | 11 BRACKET AS | 1 | |
| 4500998 | 12 SPACER (13.5X25X12-MM THK) | 2 | |
| 4679144 | 13 HOSE AS | 1 | |
| 4786448 | 14 TUBE AS | 1 | |
| 4786449 | 15 HOSE AS | 1 | |
| 0919035 | 16 SPACER (11X25X20-MM THK) | 1 | |
| 1591503 | 17 CLAMP-HOSE | 1 | |
| 1759079 | 18 ROD-LINK | 1 | |
| 1803998 | 19 STUD (M10X1.5X55-MM) | 1 | |
| 1P4278 | 20 CLAMP-HOSE | 1 | |
| 1S0996 | 21 CLIP | 2 | |
| 2287090 | 22 SEAL-O-RING | 1 | |
| 2385080 | 23 SEAL-O-RING | 2 | |
| 3196225 | 24 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309767 | 25 CONNECTOR AS | 1 | |
| 1569791 | CONNECTOR-SPECIAL | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3445675 | 26 NUT (M10X1.5-THD) | 3 | |
| 4I7889 | 27 SPACER (11X25X45-MM THK) | 1 | |
| 5C7261 | 28 NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 29 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 5P9299 | 30 CLIP (LOOP) | 2 | |
| 6D4244 | 31 CLIP (LOOP) | 4 | |
| 6D4247 | 32 CLIP | 5 | |
| 7X7729 | 33 WASHER (11X25X3-MM THK) | 1 | |
| 8T1887 | 34 CLIP (SLOT) | 1 | |
| 8T1888 | 35 CLIP (TAB) | 1 | |
| 8T1891 | 36 CLIP (SLOT) | 2 | |
| 8T1892 | 37 CLIP (TAB) | 2 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 40 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4172 | 41 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4176 | 42 BOLT (M12X1.75X90-MM) | 1 | |
| 8T4177 | 43 BOLT (M8X1.25X90-MM) | 1 | |
| 8T4179 | 44 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4182 | 45 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4195 | 46 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 48 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T7934 | 49 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 8W1253 | 50 SPACER (11.06X15.88X60-MM THK) | 1 | |
| 5P5991 | 51 HOSE (0.4-M) | ||
| 4231983 | 52 HOSE (38-IN) |
