System And Components
461-2428 INSTALLATION GP-COMMUNICATION -PL641E CELLULARS/N KMR1-638; TMY1-384; HTZ1-708
Group No: 461-2428
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT)(COMMUNICATIONS) | 2 | |
| 1243019 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3376811 | 3 BRACKET | 1 | |
| 3496083 | 4 CABLE AS | 1 | |
| 4402105 | 5 CONTROL GP-ELECTRONIC (PL641E CELLULAR) | 1 | |
| 4438463 | 6 ANTENNA AS | 1 | |
| 3858201 | CAP AS-CONNECTOR | 1 | |
| 4566921 | 7 PLUG AS-CONNECTOR | 1 | |
| 1552264 | PLUG AS-CONNECTOR | 1 | |
| 4612424 | 8 COVER AS | 1 | |
| 4612425 | 9 HARNESS AS-CONTROL (PRODUCT LINK) | 1 | |
| 4848305 | 10 BRACKET AS | 1 | |
| 4848306 | 11 BRACKET | 1 | |
| 4926282 | 12 GROMMET | 1 | |
| 1325789 | 13 CLIP (LADDER) | 1 | |
| 1566175 | 14 CLIP (LADDER) | 1 | |
| 2808912 | 15 BOLT (M10X1.5X75-MM) | 1 | |
| 3445673 | 16 NUT (M6X1-THD) | 5 | |
| 3445675 | 17 NUT (M10X1.5-THD) | 7 | |
| 3523968 | 18 CLIP (LADDER) | 2 | |
| 3812621 | 19 MOUNTING-CABLE TIE | 1 | |
| 6V7357 | 20 BOLT (M6X1X25-MM) | 4 | |
| 7K1181 | 21 STRAP-CABLE | 20 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4138 | 24 BOLT (M6X1X20-MM) | 1 | |
| 8T4178 | 25 BOLT (M10X1.5X90-MM) | 2 | |
| 8T4191 | 26 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4196 | 27 BOLT (M10X1.5X35-MM) | 1 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 10 |
