System And Components
392-6891 TANK GP-FUEL -FAST FILLS/N MG51-UP; GB61-UP
Group No: 392-6891
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9P3066 | 1 MOUNTING | 8 | |
| 1257037 | 2 INSERT | 2 | |
| 1557714 | 3 HANDHOLD | 1 | |
| 2298315 | 4 SENDER AS-FUEL LEVEL | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3634123 | 5 GASKET | 1 | |
| 4229234 | 6 HANDLE | 1 | |
| 4289226 | 7 PLATE | 1 | |
| 4772367 | 8 TANK GP-FUEL (FAST FILL) | 1 | |
| 1488410 | 9 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 5C9553 | 10 BOLT (M6X1X16-MM) | 5 | |
| 5P1076 | 11 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 6P8269 | 12 WASHER (20.5X88X6-MM THK) | 4 | |
| 6V4368 | 13 SEAL-O-RING | 1 | |
| 7X2555 | 14 BOLT (M16X2X80-MM) | 4 | |
| 8T4139 | 15 BOLT (M12X1.75X30-MM) | 8 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 5 | |
| 9X8257 | 17 WASHER (17.5X30X3.5-MM THK) | 4 |
