System And Components
396-9031 WIRING GP-ENGINES/N MG51-UP; GB61-UP
Group No: 396-9031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 40 | |
| 8T4136 | 2 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 3 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4186 | 4 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4191 | 5 BOLT (M10X1.5X16-MM) | 6 | |
| 8T4195 | 6 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4189 | 7 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4192 | 8 BOLT (M12X1.75X25-MM) | 1 | |
| 3J1907 | 9 SEAL-O-RING | 1 | |
| 3S2093 | 10 STRAP-CABLE | 11 | |
| 4P7581 | 11 CLIP (LADDER) | 7 | |
| 5P4116 | 12 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9W0742 | 16 BLOCK GP-JUNCTION (BATTERY) | 1 | |
| 1275447 | 17 SPACER (10.5X20X12-MM THK) | 1 | |
| 1757141 | 18 NUT-HEX FLANGE (M10X1.5-THD) | 1 | |
| 2033847 | 19 BRACKET AS | 1 | |
| 1712419 | STUD-WELD (M10X1.5X35-MM) | 1 | |
| 2345013 | 20 SENSOR GP-TEMPERATURE (TORQUE CONVERTER) | 1 | |
| 2676197 | 21 INDICATOR-AIR FILTER CHANGE | 1 | |
| 3066687 | 22 STRAP AS | 2 | |
| 3474125 | 23 CABLE AS | 1 | |
| 3L6513 | TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW) | 1 | |
| 8T8827 | BOOT (RED) | 2 | |
| 6T5598 | TERMINAL-RING (1-GA TO 2-GA, 5/16-IN SCREW) | 1 | |
| 8C3056 | CABLE (2-GA, RED)(160-CM) | ||
| 3484445 | 24 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 3484939 | 25 CABLE | 1 | |
| 3491178 | 26 SENSOR-PRESSURE (DIFFERENTIAL PRESSURE) | 1 | |
| 4457683 | 27 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 2 | |
| 4457684 | 28 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1787023 | BOSS (M10X1.5X30-MM) | 1 | |
| 4495872 | 29 WIRE AS | 1 | |
| 4758472 | 30 HARNESS AS-ENGINE | 1 | |
| 1013129 | 31 STUD (M10X1.5-THD) | 1 | |
| 1057781 | 32 SPACER (13.5X25X40-MM THK) | 1 | |
| 1240174 | 33 CLIP (LOOP) | 1 | |
| 1470385 | 34 CLIP | 1 | |
| 1488307 | 35 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 1772215 | 36 STRAP-DUAL CLAMP | 1 | |
| 2062423 | 37 SADDLE-MOUNTING | 3 | |
| 2321693 | 38 BOLT-FLANGE HEAD (M6X1X35-MM) | 1 | |
| 3523964 | 39 CLIP (LADDER) | 1 | |
| 3523968 | 40 CLIP (LADDER) | 1 | |
| 3523970 | 41 CLIP (LADDER) | 1 | |
| 3838589 | 42 SENSOR GP-TEMPERATURE (ATAAC) | 1 | |
| 2287103 | SEAL-O-RING | 1 | |
| 2566454 | SENSOR-TEMPERATURE (2-PIN)(AIR COOLING) | 1 | |
| 4P7428 | 43 CLIP (LADDER) | 2 | |
| 4P8134 | 44 CLIP (LADDER) | 3 | |
| 5P7464 | 45 CLIP (SLOT) | 1 | |
| 5P7465 | 46 CLIP (TAB) | 1 | |
| 6V1249 | 47 GROMMET (22-MM ID) | 1 | |
| 8T4648 | 48 BOLT (M12X1.75X70-MM) | 1 |
