System And Components
399-0227 WIRING GP-GRADE CONTROL -CHASSISS/N MG5976-UP; GB6447-UP
Group No: 399-0227
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 7K1181 | 2 STRAP-CABLE | 30 | |
| 7R3029 | 3 CAP-DUST | 3 | |
| 9W4361 | 4 MOUNT-FLEXIBLE | 4 | |
| 1317546 | 5 GROMMET | 1 | |
| 1328487 | 6 NUT-RING | 3 | |
| 4556348 | 7 MODULE AS-POWER SUPPLY | 1 | |
| 2584819 | 8 BOSS | 3 | |
| 3423831 | 9 BRACKET AS | 1 | |
| 6V8224 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3442542 | 10 BRACKET | 1 | |
| 3602968 | 11 HARNESS AS-WIRING (POWER MODULE, RH) | 1 | |
| 3602969 | 12 HARNESS AS-WIRING (POWER MODULE, LH) | 1 | |
| 3941921 | 13 HARNESS AS-RADIO | 1 | |
| 4472874 | 15 HARNESS AS-HOOD | 1 | |
| 4476233 | 16 HARNESS AS-FRONT | 1 | |
| 4627039 | 17 HARNESS AS-CONTROL (POWER MODULE) | 1 | |
| 4653501 | 18 PLATE AS | 1 | |
| 1240174 | 19 CLIP (LOOP) | 1 | |
| 1241479 | 20 CLIP (LOOP) | 2 | |
| 1325789 | 22 CLIP (LADDER) | 3 | |
| 1797262 | 23 SCREW-FLAT HEAD (M8X1.25X40-MM) | 3 | |
| 1984777 | 24 WASHER-HARD (11X25X10-MM THK) | 3 | |
| 2062423 | 25 SADDLE-MOUNTING | 1 | |
| 4D7735 | 26 CLIP | 1 | |
| 4D9517 | 27 CLIP | 1 | |
| 4P7581 | 28 CLIP (LADDER) | 2 | |
| 5C2890 | 29 NUT (M6X1-THD) | 4 | |
| 5P4116 | 30 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6D3033 | 31 SCREW-SOCKET HEAD (4-40X0.5-IN) | 12 | |
| 6V8801 | 32 NUT (3/8-16-THD) | 8 | |
| 7X2533 | 33 BOLT (M6X1X35-MM) | 8 | |
| 8T4121 | 34 WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 8T4133 | 35 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 36 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 37 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4196 | 38 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4205 | 39 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T7547 | 40 BOLT (M8X1.25X30-MM) | 2 | |
| 1336934 | 41 SPACER (11X20X25-MM THK) | 1 | |
| 9X8256 | 42 WASHER (6.6X12X2-MM THK) | 8 | |
| 8T4186 | 43 BOLT (M10X1.5X40-MM) | 4 | |
| 9G8140 | 44 SPACER (10.5X25X15-MM THK) | 8 | |
| 3445675 | 45 NUT (M10X1.5-THD) | 4 | |
| 4800121 | 46 BRACKET | 1 | |
| 4800122 | 47 COVER AS | 1 |
