System And Components
521-4809 WIRING GP-GRADE CONTROLS/N MG51-UP; GB61-UP
Group No: 521-4809
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4186 | 1 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4195 | 2 BOLT (M10X1.5X30-MM) | 3 | |
| 1837121 | 3 BOLT (M10X1.5X35-MM) | 3 | |
| 4990546 | 4 MOUNT AS | 4 | |
| 7X2533 | 5 BOLT (M6X1X35-MM) | 8 | |
| 3S2093 | 6 STRAP-CABLE | 9 | |
| 4D9517 | 7 CLIP | 1 | |
| 4P7581 | 8 CLIP (LADDER) | 2 | |
| 5C2890 | 9 NUT (M6X1-THD) | 4 | |
| 6D3033 | 10 SCREW-SOCKET HEAD (4-40X0.5-IN) | 12 | |
| 7K1181 | 11 STRAP-CABLE | 33 | |
| 7R3029 | 12 CAP-DUST | 3 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4205 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 8 | |
| 1240174 | 19 CLIP (LOOP) | 3 | |
| 1317546 | 20 GROMMET | 1 | |
| 1325789 | 21 CLIP (LADDER) | 4 | |
| 1328487 | 22 NUT-RING | 3 | |
| 1336934 | 23 SPACER (11X20X25-MM THK) | 1 | |
| 1797262 | 24 SCREW-FLAT HEAD (M8X1.25X40-MM) | 3 | |
| 1984777 | 25 WASHER-HARD (11X25X10-MM THK) | 3 | |
| 2584819 | 26 BOSS | 3 | |
| 3445675 | 27 NUT (M10X1.5-THD) | 16 | |
| 3469759 | 28 PLATE AS | 1 | |
| 3523964 | 29 CLIP (LADDER) | 1 | |
| 3941921 | 30 HARNESS AS-RADIO | 1 | |
| 4476233 | 31 HARNESS AS-FRONT | 1 | |
| 4556348 | 32 MODULE AS-POWER SUPPLY | 1 | |
| 4653501 | 33 PLATE AS | 1 | |
| 5097657 | 34 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 5149151 | 35 BRACKET | 1 | |
| 5197035 | 36 HARNESS AS-CONTROL (POWER MODULE) | 1 | |
| 5214810 | 37 HARNESS AS-CONTROL (GRADE) | 1 | |
| 5223370 | 38 BRACKET AS | 1 | |
| 2062423 | 39 SADDLE-MOUNTING | 1 | |
| 3602968 | 40 HARNESS AS-WIRING (POWER MODULE, RH) | 1 | |
| 3602969 | 41 HARNESS AS-WIRING (POWER MODULE, LH) | 1 | |
| 1288678 | 42 SPACER (10.5X25X15-MM THK) | 8 | |
| 5096581 | 43 SEAL-BULK (3-CM EACH) | ||
| 5096581 | 43A SEAL-BULK (4-CM EACH) |
