System And Components
419-9109 ENCLOSURE GP-ENGINES/N MG51-UP; GB61-UP
Group No: 419-9109
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1257037 | 1 INSERT | 2 | |
| 3505622 | 2 BRACKET | 2 | |
| 3838650 | 3 SHIM | 2 | |
| 4157988 | 4 BRACKET AS (LH) | 1 | |
| 4157989 | 5 BRACKET AS (RH) | 1 | |
| 4211442 | 6 COVER (LH) | 1 | |
| 4211443 | 7 COVER AS (RH) | 1 | |
| 4228738 | 8 BRACKET AS | 2 | |
| 4525145 | 9 PANEL GP-HOOD (FRONT) | 1 | |
| 1462282 | 10 COLLAR | 8 | |
| 3445675 | 11 NUT (M10X1.5-THD) | 6 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 18 | |
| 7Y2854 | 13 SPACER (24X38X3-MM THK) | 12 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4191 | 15 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4222 | 18 WASHER-PLATED (11X32X2.5-MM THK) | 12 | |
| 2025293 | 19 SEAL (1-DM EACH) | ||
| 2025293 | 19A SEAL (6-DM EACH) | ||
| 2025293 | 19B SEAL (1.3-DM EACH) | ||
| 2025293 | 19C SEAL (3.4-DM EACH) |
