Assembly
100%

384-7410 FRAME GP-UNDERCARRIAGE -HEAVY-DUTYS/N GB61-UP

Group No: 384-7410
Part NumberPart NameQty
19015461 IDLER GP-TRACK4
19670742 STRIP-WEAR (REAR)4
19670783 STRIP-WEAR (FRONT)4
23303674 CAP GP-TRACK IDLER (FRONT, RH)(FRONT, LH)2
23308545 CAP GP-TRACK IDLER (FRONT, LH)(FRONT, RH)2
25186016 SCRAPER2
25500457 CAP GP-TRACK IDLER (REAR, RH)2
35151138 FRAME GP-TRACK ROLLER (HEAVY-DUTY, SYSTEMONE)1
35872399 ROLLER GP-TRACK-SINGLE FLANGE4
384327510 ROLLER GP-TRACK-DOUBLE FLANGE10
255004611 CAP GP-TRACK IDLER (REAR, LH)2
8T418312 BOLT (M12X1.75X40-MM)4
8T419213 BOLT (M12X1.75X25-MM)24
8T422314 WASHER-HARD (13.5X25.5X3-MM THK)28
